Bridge assembly disassembly training desk

1. Use Volkswagen Passat rear bridge assembly (complete accessories, easy to disassemble), and install it on a dedicated flipper. The use of a deceleration agency can rotate the front bridge to rotate any angle and lock at any position, so that students can disassemble and assemble students from different angles.

2. Place the oil disk at the bottom to facilitate the centralized storage of small parts or screws.

3. The turning rack is welded with high -intensity steel structure, and the surface is treated with spraying process. The bottom of the flipper has a self -locking foot wheel, which can be moved to facilitate teaching.



two. Technical specification

Equipment shape: 100 × 600 × 1100mm (length × width × height)

Color: 7032

Steel pipe: 40*40*3mm

Universal foot wheel

The first two universal band lock function foot wheels

2 After the two thousand -facing foot wheels

The foot wheel and the table frame are fixed with the M6*4 screws, which is convenient for equipment m--ntenance and m--ntenance.

Foot wheel: 60mm × 50mm (diameter × width)

Foot wheel support: 1.0T

Soldiers: MOPA70; 1: 70

Purpose:

1. Suitable for engineering fluid mechanics (hydropower) teaching experiments.

2. Demonstrate the working principle of the water shock and the water shock wave transmission (the use of water strike energy).

3. Demonstrate the working principle of the pressure reduction of the pressure tube.

M--n configuration:

Water pump, pressure meter, constant water tank, water collection tank, water strike room, pressure room, water supply pipe, pressure regulating cylinder, water outlet pipe, valve, st--nless steel frame.

Technical Parameters:

1. Operating environment: temperature 0-40 ° C, relative humidity: ≤90%RH, power supply: 220V/50Hz. Can be continuously operated.

2. Practical water head: 250mm ± 10 mm, water shock increased greater than 3000mm.

3. Pressure tube regulation ratio: η> 60%.

4, pressure gauge: medical precision small volume pressure gauge.

5. The water outlet pipe of the water meter: 400mmH20, water shock Yangshui machine ** Yang Yang: 370mm, water shocking the water machine to reach 1.5 times the water head.

6. Flow: water supply ** flow QMAX = 300 ml/s; experimental pipeline flow QP = 0 ~ 200 mL/s.

7. Constant water tank, water collection tank, water supply pipe, pressure regulating cylinder, water outlet pipe, water strike room, and pressure chamber are made of organic glass. The experimental principle is clear at a glance.

8. Low noise -free water pump, r--sing: 10m, ** traffic: 12L/min, speed: 2800r/min, power: 100W.

9. The fluid-water used in the experiment is designed with a full circular use, which fully saves water resources.

10. The frame and countertops are made of 304 st--nless steel. The structure is compact, the appearance is beautiful, and the operation is convenient.

11. Dimensions: 1100 × 500 × 1700mm (length × width × height), the frame is a mobile design, with a foot wheel and imprisoned feet.
